¡öGSF2000-1 Fiber-optical repeater station

Applications
GSF2000-1 Fiber-optical repeater station is the DFB-LD Fiber-optical transceiver. Used to connect analog RF signal of GSM/CDMA/WCDMA systems . Build-in FSK data modulator-demodulator can transfer monitor signal of system and network management controlling data conveniently. Build-in WDM can make 1310nm and 1550nm wavelength transfer in the same optical fiber. According to customers' different demands, it can be allocated FC/APC. SC/APC interface. Suitable for the wireless access, PCS, IMT-2000, LAN, satellite communication etc. GSF2000-1.

Function And Characteristics

1. 1310nm and 1550nm lower noise lasers. low back reflection losses
2. Optical Fiber transferring distance is long (Customers' requirements have the following ways: greater than 5 km. 10km. 20km etc.)
3. -20¡æ~+70¡æ operating temperature
4. Excellent self-detecting performance (Alarm and scene indicate function)
5. Wide RF input range
6. Auto. Power Control £¨APC£©
7. Multi-status monitor and warning
8. Build-in WDM£¬1550nm and 1310nm WDM
9. Build-in FSK modulate and demodulate module; Modulate ratio 19.2Kbps
