¡ö TS Re-Multiplexer TSM-B
|
|
Features
• According to ISO/IEC 13818-1:1996,
ETSI EN 300468 standards
• TS Input: 8
ASI inputs
188/204 Byte auto detection.
Max 216Mbps bit rate.
Supports outburst mode.
• TS Processing:
Multiplex according to PID / Program.
Supports PID filtering and remapping.
PSI/SI filtering and regeneration.
Supports PSI/SI insertion.
PCR restamping, PCR jitter ¡Ü50ns
• 2 ASI
outputs, 0~108Mbps tuneable ( 1Mbps/step).
•
Remote Control via RJ45.
|
ASI Input
|
UNIT
|
SPECIFICATIONS
|
|
Number of Ports
|
-
|
8
|
|
Connector Type
|
-
|
BNC, 75¦¸
|
|
Interface Type
|
-
|
Asynchronous Serial Interface (ASI)
|
|
Packet Format
|
Byte
|
188 / 204 auto detection
|
|
Bit Rate
|
Mbps
|
Max. 216Mbps
|
|
Syntax
|
-
|
SPTS or MPTS
|
|
ASI Output
|
|
Number of Ports
|
-
|
2
|
|
Connector
|
-
|
BNC, 75¦¸
|
|
Interface Type
|
-
|
Asynchronous Serial Interface (ASI)
|
|
Bit Rate
|
Mbps
|
0~108, 1Mbps/step
|
|
Syntax
|
-
|
SPTS or MPTS
|
|
Remote Control
|
|
Number of Connectors
|
-
|
1
|
|
Connector Type
|
-
|
RJ-45
10/100M
Ethernet + TCP/IP
|
|
OTHERS
|
|
Power Supply
|
V
|
AC 220V, 50Hz
|
|
Power
|
W
|
25
|
|
Dimensions
|
mm
|
480x360x44 (19¡¯
1RU)
|
|
