Features
 High quality Chinese amplifier module.
 33dB gain.
 Adjustable attenuator.
 Adjustable equalizer.

RF	Unit	Specifications
Frequency	MHz	47~862
Gain	dB	33
Suggested Input Level	dBμV	68~72
Number of Outputs	-	1, F connector
Return Loss	dB	≥12
Flatness	dB	±0.75
Noise Figure	dB	≤8
CSO	dB	≥60
CTB	dB	≥60
Equalizer Range	dB	10
Attenuator Range	dB	20
Others
Power Supply	V	AC 90~265 V
Power	W	≤3.5
Size	mm	130x110x40
