Features
•  Suitable for use in CATV network without return path.
•   -6~+2dBm optical input range.
•   47~870MHz RF frequency range.
•   One RF output port.
•   Adjustable attenuator.
•   Compact aluminium housing, easy for fix and maintenance.

Optical	Unit	Specifications
Optical Input	dBm	-6~+2 dBm  (suggested input: -1 dBm)
Wavelength	nm	1290~1580
Reflection Loss	dB	≥45
Optical Link C/N	dBc	≥50
Optical Link C/CSO	dBc	≥62
Optical Link C/CTB	dBc	≥64
* 77-CH PAL analog signal flatness input, 0dBm optical receiving.
Connector	-	SC/APC or FC/APC
RF
Frequency	MHz	47~870
Reflection Loss	dB	16
Output Level	dBμV	≥96, Optical Receiving @ 0dBm
Flatness	dB	±1
Connector	-	F connector
Power Supply
Power Supply	V	AC 90~280V
Power	W	≤3.5
Hum Modulation	dB	-65, Bypass Current @ 10A
Others
Working Temperature	℃	-25~+55
Dimensions	mm	130X110X40
Weight	kg	1.0
